PROJECTS

North-South Commuter Railways: CP01 Viaduct Works - Construction of Drainage - Grade Drainage Mainline

Work Scope:
        • Excavation for Drainage Pipe/Channel in Mainline
        • Structural Concrete 28 mPa, Mainline Drainage Channel
        • Blinding Layer/Lean Concrete, 15mPa for Drainage Channel
        • Reinforcing Steel, Grade 40 & 60 for Drainage (Mainline)
        • RC Pipe Culverts, class C bedding in Mainline
        • Grouted Riprap, Class A
        • Manhole/Catch Basin
        • Placing and Compaction of Sand Bedding
Client:


Rectification of Ayala Nuvali Waterway Bridge (WB-27) Slope Protection

Work Scope:
        • Temporary Enclosure (Sand Bag Barriers)
        • Hauling (568 m³)
        • Manual Trimming Works
        • Removal of Actual Structures
        • Excavation
        • Grouted Riprap, Class A
        • Stone Masonry Wall
        • Apron
        • Reinforcing Steel (Anchor Block)
        • Structural Concrete (Anchor Block)
Client:


North - South Commuter Railways:
CP01 Viaduct Works -
Parapet Base Wall / End Wall

Work Scope:
        • Surveying of Lay-out points and positions
        • Assembly of Form Traveller
        • Installation of Rebar and Anchor U-Bolt
        • Fabricated Frame for Setting of U-Bolt
        • Formworks Installation for Base Columns
        • Casting of Base Columns
        • Formworks Installation for Mid Segments
        • Casting of Mid Segments
        • Dismantling of Formworks
        • Curing of Concrete
Client:


Armerad Cornerstone Construction Corporation
